Adjustment range:
Welding current / welding voltage
TIG
MIG/MAG
|
10A / 10.4V – 510A / 30.4V
15A / 14.8V – 480A / 38V
|
|
Duty cycle at 40°C
Ambient temperature: 40%duty cycle
60%duty cycle
100%duty cycle
Duty cycle at 20°C
ambient temperature: 40%duty cycle
60%duty cycle
100%duty cycle
|
480A
420A
325A
500A
440A
340A
|
|
Duty cycle
|
10min (60%: 6min ON, 4min OFF)
|
|
Open circuit voltage
|
70V
|
|
Mains voltage (tolerances)
|
3x400V (-10%, +20%)
|
|
Frequency
|
50/60Hz
|
|
Mains fuse (slow-blow)
|
35A
|
|
Mains cable, cross section
|
4x4mm²
|
|
Max. power consumption
|
25.8kVA
|
|
recommended generator power
|
32kVA
|
|
cosϕ / efficiency
|
>0.95 / 91%
|
|
Insulation class / type of protection
|
H / IP23
|
|
Ambient temperature
|
<45°C
|
|
Device cooling
|
air
|
|
Workpiece cables, cross section
|
70mm²
|
|
Dimensions L / B / H [mm]
|
450x400x540
|
|
Weight
|
49kg
|
|
Designed to standards
|
EN 60974 / IEC 60974 / VDE 0544
EN 50199 / VDE 0544 Teil 206 / SPW99
|
